MTX-C

Moisture Transmitter for Continuous Monitoring

$465.00

The MTX-C transmitter is designed for applications requiring continuous monitoring of moisture in wood and other hygroscopic materials. The transmitter generates a current or voltage output and interfaces with a PLC, data logger or computer using a 4-wire transmission. The MTX-C does not have a display. DC voltage powers the unit using a separate wire from the voltage or current output wire. Contact our customer service team to discuss your application and receive a prompt quotation at sales@delmhorst.com.

What is in the box?

MTX-C Moisture Transmitter
216CAB-0023 Output Cable
219ADA-0029 Power Adapter
Product Data Sheet
Output Chart

Have any questions? Get in Touch

Features

Moisture range - 6% - 60% wood (Douglas Fir)
Single input
DC current - 4 to 20mA, Voltage 1-5 VDC and 0-2VDC
Power supply - 15-25 VDC, 2.5mm center positive jack
Sensor inputs – UHF connector and 2-wire terminal strip
Minimum supply current - 500mA
Operating temperature range - 32F - 158F / 0C - 70C
ABS wall-mountable housing - 3.25in x 3.25in x 1.25in (mounting base 4.25in X 3.295in)
The package includes: MTX-C transmitter, 18v power adapter (p/n 219ADA-0029) output plug (p/n 216CAB-0023)
